SMA Connector | RF Coaxial Connector

Antenna PCB Board Designs-PCB antenna designs often need a reliable coaxial connection for testing, validation, or external antenna integration. This SMA connector provides a compact right-angle interface that keeps the RF port close to the board surface, helping maintain a clean layout in space-limited designs. As an SMA right angle jack for antenna PCB board applications, it is commonly used in embedded boards, antenna modules, and RF designs where a stable connection and low-profile installation are required.
Wireless Module Assemblies-Wireless modules typically require a standard antenna interface for development, testing, and production assembly. This RF coaxial connector uses a 50Ω interface with a right-angle structure, making it easier to integrate into compact module layouts while providing a reliable connection for the antenna system. The 90 degree SMA jack for wireless module applications is suitable for Wi-Fi, Bluetooth, LoRa, 802.15.4, and other wireless communication boards where PCB space and mechanical stability are important.
Communication Equipment & RF Systems-Telemetry terminals, repeaters, and other RF communication equipment often require connectors that can withstand repeated connections and long-term operation. This SMA female connector provides a secure coaxial interface with strong PCB mounting support, making it suitable for communication devices, RF modules, and equipment requiring dependable antenna connections. It can also be used for panel feed-through designs where the antenna is mounted outside the enclosure while the RF circuit remains protected inside.
Compact IoT Devices & Industrial Electronics-Trackers, sensors, gateways, and handheld wireless devices often have limited internal space and strict enclosure requirements. The compact design of this SMA female jack right angle PCB mount connector helps reduce installation height while keeping the antenna connection reliable. It is suitable for IoT and industrial wireless applications where a low-profile RF connection is needed without compromising assembly flexibility.
Panel Mount & External Antenna Applications-For equipment with metal housings or applications requiring an external antenna, a panel-mounted RF connection provides a practical way to bring the signal outside the enclosure. This 90 degree SMA female PCB connector allows the antenna to connect externally while keeping the PCB and RF module protected inside the housing. The short thread design is suitable for thin panels and compact enclosures, making it a good fit for space-limited wireless equipment.
